PRODUCT OVERVIEW
The Cooperheat SideKick® is a cutting-edge heat treatment solution designed for maximum efficiency and convenience. Using your existing welding machine as a power source, this compact unit offers two independent channels of resistance heating capability, allowing for precise and controlled heat treatment of up to 3 heaters across each zone.
The unit features an industrial 12” touch screen with the Cooper8™ programmer/recorder for user friendly setup, control and monitoring of heat cycles. It is equipped with an integrated data recording system and remote access, the SideKick® enables real-time monitoring and documentation, ensuring seamless control over your heat treatment processes.
With our new COOPERMASTER™ mobile app, you can connect to the unit and control it through your phone.
Product description
The Cooperheat SideKick offers a solution for common heat treatment processes such as preheating, hydrogen bake-out, post-weld heat treatment (PWHT), and stress relieving. By operating directly from an existing welding machine power source, the SideKick provides precise temperature control to prevent materials from cracking or distorting during preheating.
The SideKick also supports hydrogen bake-out. It removes harmful hydrogen from welds to avoid fragility in high pressure environments, maintaining the integrity of critical components. Additionally, it delivers uniform heat distribution for PWHT, and its accurate and consistent heat application during stress relieving helps reduce residual stresses in welded materials, resulting in improved durability.
Product specifications
Electrical specifications:
- Input voltage: 90Vac to 120Vac
- Freq: 48 – 62 Hz
- Max Current Draw: 1 A
- Operating Temperature Range: -32F – 120F
- Thermocouple input type: K
Dimensions
- Case dimensions:
– Width: 16 in (406 mm)
– Height: 20 in (508 mm)
– Depth: 10.5 in (267 mm)
Process
- Resistance Heating
Number of Channels
- 2 channels
Welding Power Source
- 350 amps +
Weight
- 16 kg (35 lbs)
Product resources
Sidekick® Quick Start Guide
Sidekick® User Manual
Calibrating the Sidekick®
Cooper8 Computer Software Installer V2025.04-01
Cooper8 Computer Application Manual V1.1
End User License Agreement (EULA)
Changing the IP address on Teltonika radios
Downloading files to HMI
Uploading configuration files to Watlow modules
Product images
Product related video materials
Frequently asked questions
What is the Cooperheat SideKick® and how does it work?
The Cooperheat SideKick® is a compact, high-performance heat treatment solution that uses your existing welding machine as its power source. It provides two independent resistance heating channels, allowing for precise and controlled heat treatment without the need for a dedicated transformer.
How many heaters can the SideKick® control?
The SideKick® offers two independent heating zones and can control up to three heaters per zone, enabling accurate temperature control across multiple heating points during a single heat treatment cycle.
What control and monitoring features does the SideKick® offer?
The unit features a 12” industrial touchscreen powered by the Cooper8™ programmer/recorder, providing an intuitive interface for setting up, controlling, and monitoring heat cycles. Operators can easily view real-time temperatures and cycle progress directly from the screen.
Does the SideKick® record heat treatment data?
Yes. The SideKick® includes an integrated data recording system with remote access, allowing users to monitor heat treatment processes in real time and securely record data for documentation, traceability, and quality assurance purposes.
Can the SideKick® be controlled from a mobile device?
Yes. With the COOPERMASTER™ mobile app, users can connect to the SideKick® and control the unit directly from their smartphone, offering added flexibility and convenience both on-site and remotely.
